AGENCIES

Maelgwyn Mineral Services

The company offers a unique blend of its skills in design, research, and product development combined with significant experience in mining process operations. MMS’s aim is to develop and commercialize a range of patented and proprietary technologies owned by the company in mining, chemical, and waste processing. To this end, MMS has become a world leader in the development and implementation of advanced technologies for the mining process and environmental industries.

Main Products

• Aachen High Shear Reactors For Increased Gold And Silver Recovery

The Aachen Reactor is a high-efficiency mass transfer device developed from Maelgwyn’s experience in Imhoflot flotation technology. The unit can be used in any application requiring thorough gas–liquid mixing but is particularly suitable for gold and silver leach applications where increased dissolved oxygen levels before or during leaching are needed. Historically, many operations have worked to increase dissolved oxygen in leach tanks using various methods of air and/or oxygen injection, but large oxygen bubbles quickly rise and exit the tank, making the process inefficient and oxygen-intensive. The second drawback of such systems is their failure to address surface passivation caused by oxidized species that can slow the leaching reaction. In contrast, the Aachen High Shear Reactor can generate significantly higher dissolved oxygen levels while using high shear forces to scrub mineral surfaces. The net benefits include:
- Higher gold recovery/lower tail grades
- Accelerated leach kinetics
- Reduced cyanide consumption
- Improved oxygen utilization
- Increased throughput without compromising recovery

• Maelgwyn Imhoflot Advanced Reactor Flotation

Imhoflot pneumatic flotation technology has evolved through 25 years of industrial application, leading to the patented Imhoflot G-Cell. The cell uses centrifugal forces generated as the mineral slurry enters to rapidly recover minerals and allows for much smaller cell volumes and flotation plant footprints.
Features of Imhoflot:
- High selectivity in grade-recovery relationship due to very small bubble sizes and high energy in the reactor
- Effective recovery of fine (<20 µm) and coarse (>350 µm) particles when tank flotation is inefficient
- Small cell volumes and compact flotation plant footprint
- No moving internal parts
- Lower energy requirements since no rotor/stator is needed to suspend slurry
Operational Design Features & Benefits:
- The Imhoflot pneumatic flotation process concept yields higher recoveries with extremely low residence time.
- Imhoflot is characterized by high unit throughput and tolerance to wide variations in feed rate and grade.
- It can handle widely fluctuating feed conditions and recover slow-floating minerals, reducing both capital and operating costs.
- Slurry is aerated via a centrifugal pump that provides energy for thorough air–slurry mixing, yet specific power consumption is typically less than 60% of conventional rotor-stator cells.
- Required footprint is much smaller compared to other flotation systems.
- High selectivity between ore and gangue simplifies process flowsheets.
- Modular process design.
- Distribution unit, aeration unit, and separation cell design enable easy assembly and replacement of parts.

• Leachox™ Process For Flotation Concentrates

Aachen Reactors form an integral part of the Leachox process for treating gold-bearing sulfide flotation concentrates. These concentrates are often refractory to cyanide or have gold locked in pyrite or arsenopyrite, requiring very high reagent additions for adequate recovery.
The Leachox™ process comprises several interlinked Maelgwyn proprietary processes, including:
- Imhoflot G-Cell flotation
- Ultra-fine grinding using the Ro-Star mill
- Aachen Reactors
- Reactor-assisted cyanide destruction
- Ultra-fine grinding to liberate sulfide minerals as a unit operation in the Leachox process

Diemme Filtration

Diemme® was born in the early 1970s when the filter press moved beyond its traditional applications in the food industry and established itself as a process technology for solid–liquid separation in other industrial sectors. At that time, the filter press became the machine of choice for treating industrial and municipal sewage sludge, and today it continues to serve in all applications such as mining and chemical industries, power plants, oil and gas. It serves industries where high dewatering performance, low operating costs, and reliability are key factors in technology selection. Diemme® Filtration has the widest range of filters available globally in terms of size, design, and technical features. Equipment is custom designed and manufactured to suit application needs. Diemme® Filtration has also begun designing and supplying its own range of high-rate thickeners, expanding its supply scope and offering greater support to customers.

Products:

• Filter Presses

Diemme Filtration has captured a large market share in the solid–liquid filtration segment due to its ability to customize systems entirely to customer requirements. Diemme® Filtration filter presses vary in plate transport design (top or side transport), plate size, and automation level. Plate size depends on the dimensions and number of plates fitted. Diemme® Filtration plates are available in different nominal sizes (from 500 × 500 mm to 5 000 × 5 000 mm), various materials (polypropylene, carbon, PVDF, etc.), and process configurations (membrane and recessed plates).
Automation levels:
- Semi-automatic, where the operator intervenes in various stages of the filtration cycle,
- Automatic, operating with the operator in a supervisory role,
- Fully automatic, running continuous filtration cycles without any personnel intervention.
Models:
- GHT-F
- GHT5000F DOMINO
- GHT-P
- GHS
- ME
- AUTOMAT
- KE

• Thickeners / Clarifiers

Slurry Thickeners: Diemme® Filtration high-rate thickeners are the result of decades of experience in solid–liquid separation across mining, chemical, metallurgy, water treatment, and many other industries. Our commitment to R&D enables us to propose innovative solutions to optimize performance and reduce plant costs.

Strengths of Diemme® Filtration:
- Comprehensive laboratory testing on customer samples (selection and dosing of flocculants and coagulants, static and dynamic tests, rheology, mineralogy, etc.);
- Mechanical parts designed for the most demanding conditions to ensure long-term performance and reliability;
- Optimization of tank structural design (static and dynamic analysis, seismic, FEM modeling, weight optimization, etc.);
- Integration of instrumentation and control tools to optimize processes and reduce operating costs;
- IIoT connectivity;
- Comprehensive and customizable premium components;
- Global service support.
Diemme® Filtration high-rate thickeners deliver very high efficiency and are designed to complement Diemme® Filtration filter presses. Thickeners can be manufactured in diameters of 40 m and above, available in “Bridge” or “Column” versions. Depending on project specifications, they can be built entirely from carbon steel, stainless steel (with or without rubber lining), or as concrete tanks. From a process perspective, clarifier performance depends on the system’s ability to bind solids to flocculant. This occurs in the feed well at the heart of the clarifier. The incoming stream in the feed well provides mixing energy for floc formation and subsequent settling to the tank bottom. The complex design, requiring CFD modeling by Diemme® Filtration’s technical staff, results in optimized flocculant consumption, high supernatant clarity, and consistent thickened slurry density.

Gekko

At Gekko we believe in collaboration. We work “Smarter Together” with our mission to “transform mining and the environment”. As a company we have invested the time of over sixty of our outstanding people to better understand what makes us tick. …what we believe in and what drives us to be world’s best. What we discovered is that our team is passionate about transforming mining and the environment for the better and that working collaboratively is necessary to achieve our goals and those of our partners. This is how our full Gekko Systems corporate manifesto or belief was born
Gekko Manifesto: Belief.
“Only by embracing smart ideas together can we transform our world.”
We have summarised this belief in our tag line “smarter together”. It seems obvious to us that to achieve meaningful change, we have to work together.
Gekko was founded in 1996 in Victoria, Australia. Gekko began producing In-Line Pressure Jigs for continuous gravity separation. However, growing demand for energy-efficient devices prompted Gekko to rethink and develop traditional processing flowsheets. Innovative modular designs, elegant systems, and smart manufacturing have made Gekko the world technical leader in gold processing and low-energy mining solutions.

Main Technologies:

• Carbon Scout

Increase the safety and accuracy of carbon concentration measurements in CIL/CIP circuits
- Online detection of carbon levels
- Automated carbon management system
- A single measurement point for multiple CIL/CIP tanks
- pH and dissolved oxygen measurements
- XRF to measure gold on carbon for real-time gold circuit inventory
- Save over 3 hours per day with automated sampling

• Inline Leach Reactor

Intensive Leach Chemistry
- Rapid reaction kinetics for a wide range of gold and silver concentrates
- Fully optimizable for best possible gold and silver recoveries
- Increase safety by replacing open pits with a closed leaching reactor
- ILR free gold recovery exceeds 98%

• Inline Pressure Jig

State-of-the-art take on traditional jig concepts
- IPJ uses 10% of the water volume of conventional jigs
- IPJ consumes 20% less power than conventional jigs
- Easy to transport and fits in a 40 ft container

• Modular Elution Systems

Turnkey modular elution, regeneration, and Gold Room systems by Cadia Systems and Gekko
Cadia Systems and Gekko have joined forces to combine Cadia’s expert knowledge with Gekko’s state-of-the-art manufacturing facility to deliver high-capacity production and lifetime global maintenance support to customers.

• OLGA

A breakthrough in real-time gold analysis
- The world’s first gold analyzer capable of reading gold in slurries and solutions in real time
- Enables real-time control of your plant
- Minimize gold losses from process issues
- Live trends reported directly to the plant control system for instant deviation detection and correction
- Multiplexing capability to maximize circuit data in real time from key streams

NewFer

NewFer GmbH is a multinational company offering solutions and services for the beneficiation and agglomeration of iron ore. With a team of experts in this field, we strive to continuously improve our technology and processes to meet the evolving and ever-changing needs of the industry in general and of each customer individually. By embracing digitization and innovation, we aim to enhance efficiency and sustainability in iron processing, benefiting both our clients and the environment. The company’s head office is located in Eschborn, approximately 15 km from Frankfurt am Main, Germany, and a branch office is located in Kolkata, India. We are expanding, with more than 30 employees having diversified experience across Germany and India.
“Excellence in Beneficiation and Agglomeration”

FOCUSING ON TECHNOLOGY

We focus on technology. With our core strength in iron ore concentration and pelletizing, we develop customized solutions for your challenges.

ADDING INTELLIGENCE

We do not insist on large delivery packages of equipment that others can also sell; instead, we focus on engineering services and equipment that can add intelligence to your new facility or existing operation.

STAYING AGILE & FLEXIBLE

Outside the large traditional players in this field, staying agile and flexible is vital to responding quickly to your specific needs. Even the continuous and rapid growth of our company will not compromise our agility and flexibility.

WHAT WE OFFER:

Iron Ore Beneficiation:

- Feed research and beneficiation testwork (with selected laboratories)
- Flow sheet development
- Basic engineering of concentrator plants covering all engineering disciplines
- Plant audits for bottleneck removal, improvement, and capacity increase
- Delivery and installation of online quality analyzers and Advanced Process Control Systems for concentrator plants (in partnership)
- Process consultancy and “subject-matter expert” services

Iron Ore Pelletizing:

- Pelletizing testwork (with selected laboratories)
- Process design
- Complete basic and detailed engineering of pellet plants including:
  - Concentrate handling
  - Additive grinding and handling
  - Green pelletizing
  - Process gas fans, ductwork, and process gas cleaning including indurating furnace
  - Product screening and handling
- Plant audits
- Capacity increase and bottleneck removal of existing plants
- Delivery of core equipment in partnership (burner systems, pallet cars, and smart automation equipment such as pellet size measurement and Advanced Process Control Systems)
- Process consultancy and “subject-matter expert” services

Looking Ahead:

- Cold agglomeration of iron ore (curing furnaces for cold-bonded concentrates)
- Hot air cooling in pelletizing furnaces
- Conversion of sinter plants to pellet plants (“Sinter-2-Pellet”)

IMA Engineering

IMA SENSOR SOLUTIONS

Increase production efficiency intelligently
IMA smart mining sensors collect real-time geo-metallurgical and ore quality data from drill cores, drill cuttings, and ore on conveyor belts or loader buckets during production—before it reaches the ore preparation plant, concentrator, or waste stripping area.

EXPLORATION & FEASIBILITY

IMA’s smart IoT solutions in exploration, feasibility studies, or pilot phases lead to sustainable mining practices from the outset. Underground, IMA mobile sensors (in Scanmobile) scan drill core analyses and automatically capture accurate photographs of boxes without any sample preparation.

MINING

Our solutions provide accurate data throughout the mining cycle for both surface and underground mining engineers and grade control geologists. In surface mining: from blast bench to stockpiles, loading control, plant feed, or ore sorting. In underground mining: from drawpoints to hoisting conveyors, screening systems, and onward to the plant.

ORE PREPARATION

IMA is the first and only provider of sensors for concentrators linked with geo-metallurgical analysis data from heap leach pads and benches. All information gathered by sensors and crusher and particle size data contributes to predicting grindability (throughput).

BIG DATA

IMA online sensors collect analytical and process data for monitoring smart sub-processes while controlling and optimizing the entire mining process. IMA sensors integrate with mining equipment and machinery to provide big ore data from mine to mill. This is achieved with the latest technology in connectivity.
